标准系列自锁托槽
MBT转矩：SMM2-3002/SMM2-3002/SMM2-3002
Q标准转矩：SMQ2-3002/SMQ2-3302/SMQ2-3402
高转矩：SMH2-3002S/MH2-3302/SMH2-3402
低转矩：SML2-3002/SML 2-3302/SML2-3402
product center
产品中心
点击了解产品信息
| 产品参数表（MBT） | ||||||||||||
| MBT | 上牙 | 牙位 | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 |
| 转矩角 | -7° | -7° | -7° | +10° | +17° | +17° | +10° | -7° | -7° | -7° | ||
| 轴倾角 | 0° | 0° | +8° | +8° | +4° | +4° | +8° | +8° | 0° | 0° | ||
| 厚度mm | 0.75 | 0.75 | 0.59 | 0.89 | 0.8 | 0.8 | 0.89 | 0.59 | 0.75 | 0.75 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMM2-3015 | SMM2-3014 | SMM2-3013 | SMM2-3012 | SMM2-3011 | SMM2-3021 | SMM2-3022 | SMM2-3023 | SMM2-3024 | SMM2-3025 | ||
| .022“带钩 | SMM2-3115 | SMM2-3114 | SMM2-3113 | SMM2-3112 | SMM2-3111 | SMM2-3121 | SMM2-3122 | SMM2-3123 | SMM2-3124 | SMM2-3125 | ||
| 下牙 | 牙位 | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| 转矩角 | -17° | -12° | -6° | -6° | -6° | -6° | -6° | -6° | -12° | -17° | ||
| 轴倾角 | +2° | +2° | +3° | 0° | 0° | 0° | 0° | +3° | +2° | +2° | ||
| 厚度mm | 0.74 | 0.65 | 0.6 | 0.95 | 0.95 | 0.95 | 0.95 | 0.6 | 0.65 | 0.74 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMM2-3045 | SMM2-3044 | SMM2-3043 | SMM2-3042 | SMM2-3041 | SMM2-3031 | SMM2-3032 | SMM2-3033 | SMM2-3034 | SMM2-3035 | ||
| .022“带钩 | SMM2-3145 | SMM2-3144 | SMM2-3143 | SMM2-3042 | SMM2-3041 | SMM2-3031 | SMM2-3032 | SMM2-3133 | SMM2-3134 | SMM2-3135 | ||
| 产品参数表(Q标准转矩) | ||||||||||||
| Q标准转矩 | 上牙 | 牙位 | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 |
| 转矩角 | -11° | -11° | +6° | +6° | +17° | +17° | +6° | +6° | -11° | -11° | ||
| 轴倾角 | 0° | 0° | +8° | +8° | +4° | +4° | +8° | +8° | 0° | 0° | ||
| 厚度mm | 0.75 | 0.75 | 0.59 | 0.89 | 0.8 | 0.8 | 0.89 | 0.59 | 0.75 | 0.75 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMQ2-3015 | SMQ2-3014 | SMQ2-3013 | SMQ2-3012 | SMQ2-3011 | SMQ2-3021 | SMQ2-3022 | SMQ2-3023 | SMQ2-3024 | SMQ2-3025 | ||
| .022“带钩 | SMQ2-3115 | SMQ2-3114 | SMQ2-3113 | SMQ2-3012 | SMQ2-3011 | SMQ2-3021 | SMQ2-3022 | SMQ2-3123 | SMQ2-3124 | SMQ2-3125 | ||
| 下牙 | 牙位 | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| 转矩角 | -17° | -12° | +7° | -3° | -3° | -3° | -3° | +7° | -12° | -17° | ||
| 轴倾角 | +2° | +2° | +3° | 0° | 0° | 0° | 0° | +3° | +2° | +2° | ||
| 厚度mm | 0.74 | 0.65 | 0.6 | 0.95 | 0.95 | 0.95 | 0.95 | 0.6 | 0.65 | 0.74 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMM2-3045 | SMM2-3044 | SMQ2-3043 | SMQ2-3042 | SMQ2-3041 | SMQ2-3031 | SMQ2-3032 | SMQ2-3033 | SMM2-3034 | SMM2-3035 | ||
| .022“带钩 | SMM2-3145 | SMM2-3144 | SMQ2-3143 | SMQ2-3042 | SMQ2-3041 | SMQ2-3031 | SMQ2-3032 | SMQ2-3133 | SMM2-3134 | SMM2-3135 | ||
| 产品参数表(高转矩) | ||||||||||||
| 高转矩 | 上牙 | 牙位 | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 |
| 转矩角 | -4° | -4° | +11° | +13° | +22° | +22° | +13° | +11° | -4° | -4° | ||
| 轴倾角 | 0° | 0° | +8° | +8° | +4° | +4° | +8° | +8° | 0° | 0° | ||
| 厚度mm | 0.75 | 0.75 | 0.59 | 0.89 | 0.8 | 0.8 | 0.89 | 0.59 | 0.75 | 0.75 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMH2-3015 | SMH2-3014 | SMH2-3013 | SMH2-3012 | SMH2-3011 | SMH2-3021 | SMH2-3022 | SMH2-3023 | SMH2-3024 | SMH2-3025 | ||
| .022“带钩 | SMH2-3115 | SMH2-3114 | SMH2-3113 | SMH2-3012 | SMH2-3011 | SMH2-3021 | SMH2-3022 | SMH2-3123 | SMH2-3124 | SMH2-3125 | ||
| 下牙 | 牙位 | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| 转矩角 | -17° | -5° | +11° | +11° | +11° | +11° | +11° | +11° | -5° | -17° | ||
| 轴倾角 | +2° | +2° | +3° | 0° | 0° | 0° | 0° | +3° | +2° | +2° | ||
| 厚度mm | 0.74 | 0.65 | 0.6 | 0.95 | 0.95 | 0.95 | 0.95 | 0.6 | 0.65 | 0.74 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMM2-3045 | SMH2-3044 | SMH2-3043 | SMH2-3042 | SMH2-3041 | SMH2-3031 | SMH2-3032 | SMH2-3033 | SMH2-3034 | SMM2-3035 | ||
| .022“带钩 | SMM2-3145 | SMH2-3144 | SMH2-3143 | SMH2-3042 | SMH2-3041 | SMH2-3031 | SMH2-3032 | SMH2-3133 | SMH2-3134 | SMM2-3135 | ||
| 产品参数表(低转矩) | ||||||||||||
| 低转矩 | 上牙 | 牙位 | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 |
| 转矩角 | -11° | -11° | -9° | -5° | +2° | +2° | -5° | -9° | -11° | -11° | ||
| 轴倾角 | 0° | 0° | +8° | +8° | +4° | +4° | +8° | +8° | 0° | 0° | ||
| 厚度mm | 0.75 | 0.75 | 0.59 | 0.89 | 0.8 | 0.8 | 0.89 | 0.59 | 0.75 | 0.75 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMQ2-3015 | SMQ2-3014 | SML2-3013 | SML2-3012 | SML2-3011 | SML2-3021 | SML2-3022 | SML2-3023 | SMQ2-3024 | SMQ2-3025 | ||
| .022“带钩 | SMQ2-3115 | SMQ2-3114 | SML2-3113 | SML2-3012 | SML2-3011 | SML2-3021 | SML2-3022 | SML2-3123 | SMQ2-3124 | SMQ2-3125 | ||
| 下牙 | 牙位 | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| 转矩角 | -17° | -12° | 0° | -11° | -11° | -11° | -11° | 0° | -12° | -17° | ||
| 轴倾角 | +2° | +2° | +3° | 0° | 0° | 0° | 0° | +3° | +2° | +2° | ||
| 厚度mm | 0.74 | 0.65 | 0.6 | 0.95 | 0.95 | 0.95 | 0.95 | 0.6 | 0.65 | 0.74 | ||
| 宽度mm | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | ||
| .022“不带钩 | SMM2-3045 | SMM2-3044 | SML2-3043 | SML2-3042 | SML2-3041 | SML2-3031 | SML2-3032 | SML2-3033 | SMM2-3034 | SMM2-3035 | ||
| .022“带钩 | SMM2-3145 | SMM2-3144 | SML2-3143 | SML2-3042 | SML2-3041 | SML2-3031 | SML2-3032 | SML2-3133 | SMM2-3134 | SMM2-3135 | ||
| 产品编码（精致套装） | |||
| MBT转矩 | SMM2-3007 | Queen滑动自锁托槽不带钩.022”MBT | |
| SMM2-3307 | Queen滑动自锁托槽3带钩.022”MBT | ||
| SMM2-3407 | Queen滑动自锁托槽345带钩.022”MBT | ||
| Q标准转矩 | SMM2-3007 | Queen自锁托槽不带钩.022”Q标准转矩 | |
| SMM2-3307 | Queen自锁托槽3带钩.022”Q标准转矩 | ||
| SMM2-3407 | Queen自锁托槽345带钩.022”Q标准转矩 | ||
| 高转矩 | SMH2-3007 | Queen自锁托槽不带钩.022”高转矩 | |
| SMH2-3307 | Queen自锁托槽3带钩.022”高转矩 | ||
| SMH2-3407 | Queen自锁托槽345带钩.022”高转矩 | ||
| 低转矩 | SML2-3007 | Queen自锁托槽不带钩. 022”低转矩 | |
| SML2-3307 | Queen自锁托槽3带钩. 022”低转矩 | ||
| SML2-3407 | Queen自锁托槽345带钩.022”低转矩 | ||
| 产品编码（经典包装） | |||
| MBT转矩 | SMM2-3002 | Queen滑动自锁托槽不带钩.022”MBT | |
| SMM2-3302 | Queen滑动自锁托槽3带钩.022”MBT | ||
| SMM2-3402 | Queen滑动自锁托槽345带钩.022”MBT | ||
| Q标准转矩 | SMQ2-3002 | Queen自锁托槽不带钩.022”Q标准转矩 | |
| SMQ2-3302 | Queen自锁托槽3带钩.022"Q标准转矩 | ||
| SMQ2-3402 | Queen自锁托槽345带钩.022”Q标准转矩 | ||
| 高转矩 | SMH2-3002 | Queen自锁托槽不带钩.022”高转矩 | |
| SMH2-3302 | Queen自锁托槽3带钩.022”高转矩 | ||
| SMH2-3402 | Queen自锁托槽345带钩.022”高转矩 | ||
| 低转矩 | SML2-3002 | Queen自锁托槽不带钩. 022”低转矩 | |
| SML2-3302 | Queen自锁托槽3带钩. 022”低转矩 | ||
| SML2-3402 | Queen自锁托槽345带钩.022”低转矩 | ||
